Brinno Time Lapse Model APB1000 External Power Supply for Extended Battery Life
| Power Source | Brinno Battery Pack (MRB1000) (4 x 18650 cells) |
| Energy Capacity | 13,800 mAh / 49.6 Wh |
| Always-On Mode | Provides continuous power supply for low power time lapse camera or IoT application. |
| Solar Panel Requirement | Output wattage: 5W (minimum), 5V Type C connector |
| Input Port | Type C (support 5V 2A quick charger) (on battery pack) |
| Output Port | 1. Micro USB connector (for Brinno camera) 2. Type C port |
| Output Voltage & Output Current | • 5V 2A (max. for total two output) • Micro USB: continuous output 5V 500mA (Max instantaneous output 5V 1A) • Type C: continuous output 5V 1A |
| Ambient temperature | -4 °F~140 °F (-20 °C ~ 60 °C)* |
| Size (WxHxD) | 3.68 x 3.22 x1.46 in (93.5 x 82 x 27.2 mm) |
| Weight | 9.9 oz (280 g) |
| Package Contents | Brinno Battery Pack (MRB1000) x1; External Power Adapter; Hook and Loop Tape |
Brinno Time Lapse Model BCC2000: 1080P camera trio bundle with TLC2000, industrial clamp, weather-resistant case, and up to 1-year battery life.
| Contents | Camera Clamp; Magic Arm |
| Camera Mount Screw | ¼” |
| Clamping Range | Tube: 0.4- 3.5 in (10 - 90 mm) Flat surface: 0.04- 3.5 in (1 -90 mm) |
| Magic Arm Load Capacity | 6.6 lb (3 KG) |
| Clamp Load Capacity | 110 lb (50 KG) (without extension pole) |
| Size (LxWxH) | Folded: 8.2x 3.7x 1.5 in (209x 94x 39 mm) Extended: 6.9x 7.1x 2.4 in (176x 180x 60 mm) |
| Weight | 26.5 oz (750 g) (included magic arm) |
| Materials | Clamp: Stainless, aluminum Magic Arm: Stainless, metal, aluminum |
Brinno Time Lapse Model TLC2020 HDR FHD camera, ATH1000 housing, ACC1000P clamp, 99-day battery, 360-degree tripod arm, and BCC2000 Lite (2-Pack).
| Feature | Description |
|---|
| Auto-Processed Images | Automatically converts images into ready-to-share timelapse videos. |
| 99-Day Battery Life | Records for up to 99 days with 4 AA batteries (5-minute interval). |
| Durable Mount | Stainless steel clamp with two mounting options for flat and cylindrical surfaces. |
| Low-Maintenance | Includes IP67 waterproof housing for all-season protection. |
| Weatherproof Protection | IP67 waterproof housing for use in all weather conditions. |
| Long-Term Operation | Perfect for long-term timelapse projects with minimal adjustments. |
| Scheduled Recording | Allows recording only on selected days/times to conserve battery. |
